Heliport beacon light are special ighting devices used to indicate helicopter landing and takeoff areas. This beacon light usually emits a short white flash and can be observed at all azimuth angles. It may also send an “H” signal in Morse code to ensure that pilots can easily identify it.
Airport Light Features
- LED heliport beacon lights are equipped with high-strength aviation aluminum die-cast chassis with protection level IP68;
- LED lights have low power consumption and long-life LED chips;
- The flashing heliport beacon light use PC material lampshades, which are corrosion-resistant, UV-resistant and impact-resistant;
- Airport beacon lights are lightning-proof and surge-proof, and can adapt to extremely harsh working environments;
- HP/B airport warning lights have light-controlled switches that can automatically turn on/off lighting according to light control;
- Comply with FAA and ICAO aviation obstacle warning light standards;
- Adopt advanced baking paint technology, good heat dissipation performance, and reduce the size and weight of the lamp;
- With overcurrent protection function.
Parameters of Led Heliport Beacon Light
Name | Parameters |
Model | YFFY-HP/B Led Helipad Lights |
Material | Aviation aluminum casting chassis |
Power Voltage | Optional voltage: AC180V~264V |
Power Supply Frequency | 50HZ~60HZ |
Power Consumption | ≤20W |
Working Mode | Flashing 4times /2S |
Optional Emitting Light Colors | White |
Service Life of the Light Source | ≥10 years |
Light Intensity | ≥2500CD |
Overall Size(mm) | 255 x 255 x 210(mm) |
Installation Size | 234mm x M8 |
IP Protection | IP67 |
Ambient Temperature | -55℃~85℃ |
Net Weight | 3.8KG |
Lifespan | 100000 (hours) |
Horizontal Out-put | 360° |
Anti-Wind Ability | 80m/s |
Warranty | 2-3 Years |
Application
- Airport
- Heliport
- Helipad
- Other aviation obstruction
Precautions For Use
- Do not use any power supply exceeding the rated voltage, otherwise the device will be damaged.
- When the flashing heliport beacon light is not in operation, do not open it to avoid damage caused by internal high voltage.
- After installation, it is necessary to check whether the equipment is well waterproofed and whether the screws are tightened.
- Non-professionals are not allowed to repair the equipment to avoid expanding errors and causing damage.
- When the LED airport light is not used continuously, please charge it every 2-3 months (2-3 days)
Packaging Details
- Each one in bubble pack, Then in carton
- Selling Units: Single item
- Single package size: 30X30X28 cm
- Single gross weight: 4.250 kg
