Aircraft Warning Light For Tower & Crane – FAA L-810 LED Aviation Obstruction Lights
The light source adopts self-developed special LED chip, which has the characteristics of low power consumption and long life. The lampshade is made of PC material, which is corrosion-resistant, UV-resistant and impact-resistant.
The management circuit has a powerful lightning protection function and is equipped with a surge protection device, which can adapt to extremely harsh working environments.
This LED low-intensity obstruction light has a light control switch, which automatically turns on when the light intensity is less than 50LUX and automatically turns off when it is higher than 50Lux.
Parameters of Aircraft Warning Light
|
LIGHTING
|
|||
|
Model
|
YFFY-LB-01 Aviation Obstruction Light
|
||
|
Compliant With
|
FAA L-810, ICAO TYPE B
|
||
|
Emitting Color
|
Red (optional: yellow amber, green blue, white)
|
||
|
Operation Mode
|
Steady Burning / Flash Pattern
|
||
|
Vertical Divergence
|
>3°
|
||
|
Horizontal Out-put
|
360°
|
||
|
Light Source
|
LED
|
||
|
Light Lifespan
|
>100,000 Hours
|
||
|
POWER SUPPLY
|
|||
|
Voltage
|
AC220V AC120V DC48V DC24V DC12V
|
||
|
Supply Frequency
|
50HZ-60HZ
|
||
|
Power Consumption
|
≤3W
|
||
|
LED Lifespan
|
>100000 hours
|
||
|
Lamp Luminous Flux(lm)
|
300
|
||
|
Lamp Luminous Efficiency(lm/w)
|
100
|
||
|
Light Intensity
|
32.5cd
|
||
|
STRUCTURE
|
|||
|
Lens
|
PC
|
||
|
Body Material
|
Aircraft Aluminum, Die-casting aluminum alloy
|
||
|
Base Type
|
2G11
|
||
|
Color Temperature(CCT)
|
Cool white
|
||
|
Temperature Range
|
-40℃~70℃
|
||
|
Wind Load
|
120m/s
|
||
|
Overall Size(mm)
|
136×136×210
|
||
|
Installation Size(mm)
|
3/4 inches or 1 inche
|
||
|
Beam Angle(°)
|
360 Degree
|
||
|
Warranty
|
2 Years
|
||
|
Water-proof
|
IP65
|
||
|
Weight
|
1KG
|
||
Aviation Obstruction Lights Use
- Tower
- Crane
- Communication tower
- Chimney
- Runway
- Heliport
- Traffic guardrail
- Tower crane
- Block
- Bridge
- Anywhere where LED aviation obstacle warning light is needed.
Packaging of L-810 Aviation Obstruction Lights
- Packaging Details: 12pcs/carton
- Selling Units: Single item
- Single Package Size: 18X18X20 cm
- Single Gross Weight: 1.5 kg
